मोटाई
13 मिलीमीटर (mm)

शर्त
नया

उपयोग
औद्योगिक

स्ट्रक्चर
ट्यूब हीट एक्सचेंजर

वोल्टेज
220 वोल्ट (v)

Minimum Order Quantity
1 Unit

भुगतान की शर्तें
कैश इन एडवांस (CID)

आपूर्ति की क्षमता
10 प्रति महीने

डिलीवरी का समय
5-7 दिन

मुख्य घरेलू बाज़ार
ऑल इंडिया

The Edible Oil Heat Exchanger is a perfect solution for industrial usage. It has a voltage requirement of 220 volts and a thickness of 13 millimeters. The structure of the heat exchanger is designed with tubes that provide efficient heat transfer. With a new condition, this heat exchanger is reliable and highly efficient for the transfer of heat in industrial processes. The Edible Oil Heat Exchanger is manufactured, serviced and supplied by a reputable company that specializes in providing top-quality heat exchangers.

SALIENT FEATURES

Fully Automatic
Guaranteed 30 to 50% Savings In Fuel Cost
Auto Temperature Control
No Running Attention Required
Low Fuel Indication
PLC Control Panel With Colour Touch Screen
SS 304 Coil Type Insulated Heat Exchanger With 3 Pass Design
Lower Cost of Fuel Compares to Oil (HSD/LDO/FO) & Gas (LPG/PNG/CNG/Propane)

DETAILS	UNIT	JEHE-100	JEHE-200	JEHE-300	JEHE-400	JEHE-600	JEHE-800	JEHE-1000
Heat Out Put	Kcal/Hr	1,00,000	2,00,000	3,00,000	4,00,000	6,00,000	8,00,000	10,00,000
PLC Control Panel		Yes	Yes	Yes	Yes	Yes	Yes	Yes
All Std. Safety Accessories		Yes	Yes	Yes	Yes	Yes	Yes	Yes
Electrical Supply	Volts	220 volt, 1 Phase			440 volt, 3 phase
Fuel	Pallet, Natural Gas, CNG, Oil
Fuel Consumption
Gas (LPG)	Kg/Hr	3.5	14	24	28	40	56	70
Pallet	Kg/Hr	15	30	60	65	100	140	170
Oil Circulation Pump	KW	1.5	2.25	3.25	3.75	5.5	7.5	11.25
Blower/ Burner Motor	KW	0.37	0.75	1.00	1.5	2.25	3	3.75
Total Electrical Load	KW	1.87	3.75	4.25	6	8.63	12.75	16
Overall Dimensions	LxWxH	1200x800x1000	1500x1000x1200	2200x1200x1500	2400x1350x1500	2500x1500x1800	2800x1650x2000	3000x2000x2200
Dry Weight (Approx.)	KG.	800	1200	1500	1800	2500	2800	3800

Minimum Order Quantity	3 टुकड़ा
Material	Stainless Steel
Thickness	13mm
Frequency	50 Hz
Voltage	220V
Power Source	Electric
Automation Type	Semi -Automatic

FAQs of Edible Oil Heat Exchanger:

Q: What is the voltage requirement for the Edible Oil Heat Exchanger?

A: The Edible Oil Heat Exchanger requires a voltage of 220 volts.

Q: What is the thickness of the Edible Oil Heat Exchanger?

A: The thickness of the Edible Oil Heat Exchanger is 13 millimeters.

Q: What is the structure of the Edible Oil Heat Exchanger?

A: The Edible Oil Heat Exchanger is designed with tubes that provide efficient heat transfer.

Q: Is the Edible Oil Heat Exchanger a new product?

A: Yes, the Edible Oil Heat Exchanger is a new product.

Q: Who manufactures and supplies the Edible Oil Heat Exchanger?

A: The Edible Oil Heat Exchanger is manufactured, serviced and supplied by a reputable company that specializes in providing top-quality heat exchangers.
